Cubiscan 325
Top of the Cubiscan line
The Cubiscan 325 is a measuring and weighing system suitable for both regular- and irregular-shaped products, such as clothing, backpacks, tools, etc. With all the latest technologies combined, the process of collecting master data has never been easier, faster and more accurate.
The infrared sensor technology offers numerous functions that improve measurements, such as filtering through transparent material (polybags) and compressing packaging to increase space efficiency. This provides realistic master data that minimizes dimensional shipping costs and reduces packaging waste. It also minimizes your carbon footprint by reducing fuel emissions.
The Cubiscan software is designed to connect directly to your article master database and provides immediate availability of your data after measurement. With the optional mobile cart, you can scan articles anywhere in the warehouse, saving significant time and labor costs.
Developed for irregularly shaped products
Highest accuracy
Infrared sensor technology
Static or mobile version
Best choice for mixed article assortment
Service and maintenance
When purchasing a Cubiscan 325, service, maintenance and repair are of course also included. If you choose for the optional service with an SLA (Service Level Agreement), this guarantees the following annual maintenance:
- Calibration of sensors and scale;
- Adjustment of sensors;
- Checking and measuring of all cables;
- Software & firmware upgrades;
- Complete cleaning.
Maintenance can also take place without SLA on the basis of post-calculation. Our Service team is available every working day from 08:00 to 17:00, also for corrective maintenance in case of problems or help with integrating the software. Furthermore, we are of course always ready to explain all possibilities and options and support you through the spare parts process. This guarantees that your Cubiscan 325 will always function quickly and accurately to your satisfaction!
Product composition & options
The Cubiscan 325 comes with the following elements:
Fixed/basic components
- Cubiscan 325 measure and weigh unit
- Qbit-DB Software
- Barcode scanner
- Laptop tray/platform
- Calibration weight (20 kg)
- Product and user training
Optional mobility package
- Mobile cart
- Battery pack
Additional options
- IP-Camera application with camera (axis) and arm
- Compression plate
- Cubetape
- Precision scale
- Heavy scale
- SLA (annual service & maintenance)
Relevant downloads
Measuring and weighing system for irregularly shaped items
Measuring and weighing system for irregularly shaped items
Technical details
The Cubiscan 325 can measure and weigh both regularly (cuboidal) and irregularly shaped and packaged (boxes, polybags, etc.) items.
Measurement ranges
- Length max. 90 cm
- Width max. 60 cm
- Height max. 60 cm
- Weight max. 25 kg
Performance specifications
- Operating speed 3-7 seconds
- Dimensional increment 1 mm
- Weight increments 2 grams
PHYSICAL FEATURES
- Length 125 cm
- Width 97 cm
- Height 97 cm
- Weight 78.5 kg
Other
- Data output Ethernet (1), Serial (1), USB (1)
- Humidity 0% to 90% non-condensing
- Measure sensor Infrared sensing technology
- Operating temperature -10˚ to 40˚C
- Power requirements 100-240 VAC, 50-60 Hz
- Weight sensor Four load cells
